| Categories | CNC Plasma Cutting Machine |
|---|---|
| Place of Origin: | Jiangsu, China |
| Brand Name: | YAHONG |
| Certification: | ISO9001:2008 and CE |
| Supply Ability: | 200 Set/Sets per Month plasma machine |
| Packaging Details: | protective film+ pearl wool+plywood case for Plasma cutting metal for sale cheap CNC plasama cutting machine |
| MOQ: | 1 Set/Sets |
| Price: | $5,000.00 - $7,500.00 / Set |
| Warranty: | 12 months |
| Condition: | New |
| Dimension(L*W*H): | 3600mm*1000mm*1000mm |
| Rated Power: | 200w |
| Voltage: | 380V.220v |
| title: | plasma cutting machine |
| effective cutting length: | 6000mm |
| effective cutting width: | 2500mm |
| cutting thickness: | 1~according to plasma power source |
| other cutting size: | can be customized |
| cutting speed: | 0-4000mm per minute plasma cutting machine |
| ignition device: | auto ignition device |
| drive motor: | step motor or servo motor |
| cnc control system: | Shanghai FANGLING cnc control system |
| gear and rack: | class 7 high precision gear and rack |
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Weight: | 510KG |
| Port: | any port for Plasma Machine |
We have kinds of CNC plasma/laser/gas cutting metal machines ,
Please contact us,
So we can help you select the right system to meet your needs and fit your budget !
CNC Plasma Cutting Machine
YH-1530-T YH-2560 YH-1525
Fiber Laser Cutting Machine
YH-1530-L YH-2060-L YH-2040-L
Plasma cutting metal for sale cheap CNC plasama cutting machine
Other plasma metal cutting video pleaseclick:http://xzyahong.en.alibaba.com/custom_page_1/Cutting_video.html
I.Products advantages:
YH2560 CNC plasma cutting machine is an excellent model designed and manufactured by Xuzhou Yahong CNC Equipment Factory. Its main characteristics is that this model uses bilateral drive mode so that the machine can operate smoothly, have high locating accuracy and simple & good appearance. Moreover, the modularized design makes machine components have strong exchangeability and equipment function be expanded more simply & conveniently. The user can configure plasma cutting torches in different sizes according to the process requirements. Its advantages is high automation, easy operation, high accuracy, high reliability, low price, and simple operation & maintenance
II.Unique functions
(1). graphic display function
(2). English interface and other 5 languages
(3). Excellent graph library ,48 graphic
(4). steel plate correction function
(5). Kerf can be automatically compensated
(6). Cutting can continue when power fails
(7). Continuous return can be done
(8). Positioning and cutting can be done randomly
(9). Off-line cutting can be done:
(10). Online upgrading function
III. Main Technical Performance Indexes of products
1 | Product Type | cnc plasma cutting machine |
2 | LCD Display Dimension | 7.0Inches |
3 | Effective Cutting Width (X axis) | 2500mm |
4 | Effective Cutting Length (Y axis) | 6000mm |
5 | Cross Beam Length | 3000mm |
6 | Longitudinal Rail Length | 7500mm |
7 | Cutting Speed | 0-8000mm per minute |
8 | Plasma Cutting Thickness | 2--20mm ( Depends on plasma power source capacity) |
9 | Flame Cutting Thickness | 6--200mm |
10 | Drive Mode | bilateral drive |
11 | Cutting Mode | flame/plasma cut metal |
12 | Ignition device | Auto ignition device |
13 | Height regulating device | Arc voltage height and Electric adjustable high |
14 | File transmission | USB transmission |
15 | Gas Pressure | Max. 0.1Mpa |
16 | Oxygen Pressure | Max.0.7Mpa |
17 | Cutting Gas | Acetylene/Propane |
18 | Plasma Power Source | optional |
19 | Plasma Air | Only pressed Air |
20 | Plasma Air Pressure | Max. 0.8Mpa |
21 | Cutting precision | ±0.5mm National standard JB/T10045.3-99 |
22 | Control accuracy | ±0.01mm |
23 | Power Supply Voltage/Frequency | 220V/110V 50HZ / 60HZ |
24 | Rated Power Supply | 200W |
25 | Working Temperature | -10°C-60°C. Relative Humidity, 0-95%. |
IV.Products Application
V. Operating Steps:
VI.Detail Photos:
Packaging & Shipping
VII.Packaging Photos:
Packing: lining--anti-static film package firstly, waterproof, moistureproof.
Intermediate--around the perimeter of the box, there is bubble.
Outer--export standard packing, fumigation-free plywood.
Package size: 3600mm*1000mm*1000mm
weight:650KG
VIII.Cutting Samples:
YAHONG plasma cutting machine business partner
X.Why Choose US:
1. We specialized in the production and sales of CNC cutting machine
2. We are gold suppliers of alibaba
3. We have a professional sales and service team
4.Our products, quality guarantee,CE certificate, they are exported to many countries around the world, Such as Belgium. French. Indonesia. Korean. Australia . Romania. Russia. Iraq and so on.
|
