| Categories | Automatic Pick And Place Machine |
|---|---|
| Brand Name: | Charmhigh |
| Model Number: | CHM-861 |
| Place of Origin: | China |
| Certification: | CE、FCC、SGC、ISO |
| Vacuum Generation: | Built-in Vacuum Pump |
| PCB Conveying: | 3-section-rail Automatic Conveying, PCB Support |
| Weight: | 1596kg |
| Air Supply: | 0.5MPa ~0.7MPa |
| Mounting Head Quantity: | 8 |
| Mounting Speed: | 33100cph (optimal) IPC9850:25700cph |
| Nozzle Change: | Automatic Nozzle Change (37-hole Nozzle Library) |
| Control System: | Built-in Industrial Computer (Windows 7) |
| Parameter | Details |
|---|---|
| Automated Pick-and-Place System | Yes |
| Vacuum Generation | Built-in Vacuum Pump |
| Feeding System | 100 NXT 8mm Standard Feeder Stacks |
| Weight | 1596kg |
| Nozzle Change | Automatic Nozzle Change (37-hole Nozzle Library) |
| Power Supply | AC380V (50Hz, Three Phase), 4.5kW |
| Air Supply | 0.5MPa ~0.7MPa |
| Mounting Speed | 33100cph (optimal) IPC9850:25700cph |
| Component Height | 12mm |
| PCB Conveying | 3-section-rail Automatic Conveying, PCB Support |
| Mounting Head Quantity | 8 |
The Charmhigh CHM-861 Automated Pick-and-Place System is designed and developed for high-speed PCB assembly. This advanced system is equipped with a 3-section-rail automatic conveying system for PCB support. It has 8 mounting heads and a component height up to 12mm, providing a mounting speed of up to 33100cph (optimal) and 25700cph IPC9850. It is also capable of handling PCB thickness from 0.6mm to 3.5mm. This system is an ideal choice for those who require a reliable, high-speed pick and place solution.
|
